Placa de baza MSI MEG Z690 UNIFY, Socket 1700
Produse asemanatoare
Placa de baza MSI MEG Z690 UNIFY DDR5 LGA 1700 4719072886509 SPECIFICATIONS Model Name MEG Z690 UNIFY CPU Support Supports 12th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors CPU Socket LGA 1700 Chipset Intel® Z690 Chipset Graphics Interface 2x PCIe 5.0 x16 slots 1x PCIe 3.0 x4 slot AMD® CrossFire™ Technology Memory Support 4 DIMMs, Dual Channel DDR5-6666+MHz(OC) Storage 4x M.2 Gen4 x4 64Gbps slots, 1x M.2 Gen3 x4 32Gbps slot, 6x SATA 6Gb/s ports USB ports 2x USB 3.2 Gen 2x2 20Gbps (2 Type-C), 7x USB 3.2 Gen 2 10Gbps (7 Type-A), 4x USB 3.2 Gen 1 5Gbps (4 Type-A), 6x USB 2.0 LAN 2x Intel® I225-V 2.5G LAN Wireless / Bluetooth Intel® Wi-Fi 6E module, Bluetooth 5.2 Audio 8-Channel (7.1) HD Audio with Audio Boost 5 https://www.msi.com/Motherboard/MEG-Z690-UNIFY/Specification
| Caracteristici Placa de baza MSI MEG Z690 UNIFY, Socket 1700: | |
| CPU Socket | 1700 |
| Chipset | Z690 |
| Procesoare suportate | Intel 12th Generation Core/Pentium/Celeron |
| Memorii suportate | DDR5 |
| Sloturi memorie | 4 |
| Suport Dualchannel | Da |
| Frecventa memorie (MHz) | 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6133(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(JEDEC) |
| Memorie maxima suportata (GB) | 128 |
| Video integrat | Da |
| Slot video | PCI Express |
| Tip video integrat | Necesita procesor cu tehnologia Intel HD Graphics |
| Audio integrat | Realtek ALC4080 |
| LAN integrat | 10/100/1000/2500 Mbps Intel I225-V x2 |
| Interfata Serial ATA | 6 x SATA III |
| Porturi USB 3.2 | 8 |
| Tip port USB 3.1/3.2 | Type-A & Type-C |
| Porturi USB 2.0 | 2 |
| HDMI | Nu |
| VGA | Nu |
| DVI | Nu |
| DisplayPort | Nu |
| Porturi externe | PS/2 keyboard/mouse, Optical S/PDIF Out, 2 x RJ45, Audio |
| Sloturi PCI-E x4 | 1 |
| Sloturi PCI-E x16 | 2 |
| Sloturi M.2 | 5 |
| Wireless | Da |
| Bluetooth | Da |
| Format | ATX |
| Dimensiuni (L x l, cm) | 30.5 x 24.4 |
| Greutate Colet | 1.5 |
| Placa de baza MSI MEG Z690 UNIFY, Socket 1700 | |
| CPU Socket | 1700 |
| Chipset | Z690 |
| Procesoare suportate | Intel 12th Generation Core/Pentium/Celeron |
| Memorii suportate | DDR5 |
| Sloturi memorie | 4 |
| Suport Dualchannel | Da |
| Frecventa memorie (MHz) | 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6133(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(JEDEC) |
| Memorie maxima suportata (GB) | 128 |
| Video integrat | Da |
| Slot video | PCI Express |
| Tip video integrat | Necesita procesor cu tehnologia Intel HD Graphics |
| Audio integrat | Realtek ALC4080 |
| LAN integrat | 10/100/1000/2500 Mbps Intel I225-V x2 |
| Interfata Serial ATA | 6 x SATA III |
| Porturi USB 3.2 | 8 |
| Tip port USB 3.1/3.2 | Type-A & Type-C |
| Porturi USB 2.0 | 2 |
| HDMI | Nu |
| VGA | Nu |
| DVI | Nu |
| DisplayPort | Nu |
| Porturi externe | PS/2 keyboard/mouse, Optical S/PDIF Out, 2 x RJ45, Audio |
| Sloturi PCI-E x4 | 1 |
| Sloturi PCI-E x16 | 2 |
| Sloturi M.2 | 5 |
| Wireless | Da |
| Bluetooth | Da |
| Format | ATX |
| Dimensiuni (L x l, cm) | 30.5 x 24.4 |
| Greutate Colet | 1.5 |
